GE 269PLUS-D/O-261-100P-120

1. Overview

The GE 269PLUS-D/O-261-100P-120 is a motor management relay designed for the protection and management of small and medium-sized motors. It is equipped with a variety of protection and control functions, which can effectively prevent motor damage and ensure the safe and stable operation of motors under various working conditions. This product is widely used in the field of industrial automation, including industries such as oil and gas, chemical engineering, water treatment and power.

2. Parameters

• Model: 269PLUS-D/O-261-100P-120
• Voltage Range: 250 Volts Alternating Current (VAC)
• Rated Current: 10A
• Breaking Capacity: 14A
• Auxiliary Contacts: 2 Normally Open (NO), 2 Normally Closed (NC)
• Relay Type: Electromagnetic
• Operating Temperature Range: -25°C to 60°C
• Storage Temperature Range: -40°C to 85°C
• Humidity: 5% to 95% (Non-condensing)
• Protection Class: IP67
• Dimensions: 114 mm × 75 mm × 160 mm
• Weight: 7.75 Pounds
• Isolation Voltage: 250V Root Mean Square (RMS)
• Surge Voltage: 4kV

3. Product Features

• Multi-functional Protection: Provides multiple protection functions such as overload, underload, single-phase, overvoltage, undervoltage and ground fault protection, effectively preventing motor damage.
• Flexible Configuration: Parameters can be set according to user needs to adapt to various complex industrial environments.
• High Reliability: Adopts high-quality components and has undergone strict testing to ensure stable and reliable product quality.
• Easy Installation and Maintenance: Features a simple structure, easy operation and low maintenance costs.
• Digital Processing Technology: Utilizes digital processing technology to achieve accurate motor protection and control.
• Modular Design: Facilitates installation and maintenance.
• High Dependability: Suitable for industrial environments with high reliability.
• User-friendly Interface: Equipped with an LCD display and a numeric keypad for easy operation and configuration.

4. Structure and Composition

• 100-ohm Platinum Resistance Temperature Detector (RTD): Used for temperature detection.
• LCD Display: Displays information and supports multi-language display.
• RS232 Port: Used for connecting to a laptop, supporting the download of configuration files and firmware updates.
• Digital Inputs and Outputs: Supports a variety of input and output interfaces.
• Auxiliary Contacts: Provides 2 normally open and 2 normally closed contacts.

5. Application Fields

• Industrial Automation: Widely applied in industries such as oil and gas, chemical engineering, water treatment and power.
• Motor Protection: Used for the protection and control of small and medium-sized motors to ensure their safe and stable operation.
• Industrial Control: Suitable for various industrial control and automation systems.

6. Installation and Maintenance

• Installation: Adopts a modular design, which is convenient for installation and maintenance.
• Maintenance: Has a simple structure, easy operation and low maintenance costs.
• Maintenance Recommendations: Conduct regular inspection and maintenance to ensure the normal operation of the equipment.

————————————————————————————————————————————————————————————————————————
