GE 750-P5-G5-S5-HI-A20-R-E

Product Overview

The GE 750-P5-G5-S5-HI-A20-R-E is a microprocessor-based feeder protection and management relay from the GE Multilin 750/760 series. Designed for electrical distribution systems in industrial plants, utilities, substations, and critical infrastructure, the relay combines advanced protection, control, monitoring, metering, and communication functions in a single integrated platform. It provides dependable protection for feeders, transformers, buses, and associated distribution equipment while improving system reliability and operational visibility.

Built around dual-processor architecture, the relay delivers fast fault detection, event recording, and real-time system monitoring, making it suitable for both new installations and retrofit projects.

---

Technical Specifications

Parameter	Specification
Manufacturer	GE Multilin
Model Number	750-P5-G5-S5-HI-A20-R-E
Product Type	Feeder Protection Relay
Series	750/760 Feeder Management Relay
Phase Current Inputs	5 A
Zero-Sequence Current Inputs	5 A
Sensitive Ground Current Input	5 A
Control Power Range	88–300 VDC / 70–265 VAC
Frequency Range	48–62 Hz
Analog Outputs	8 × 4–20 mA
Communication Options	Modbus RTU, DNP 3.0
Setpoint Groups	4
Operating Temperature	-40°C to +60°C (-40°F to +140°F)
Storage Temperature	-40°C to +80°C (-40°F to +176°F)
Mounting	Standard 19-inch panel mounting
Protection Category	Feeder, transformer, bus protection
Pollution Degree	II

---

Key Features

Comprehensive Protection Functions

The relay provides a wide range of protection capabilities, including:

• Phase overcurrent protection
• Ground fault protection
• Sensitive earth fault protection
• Backup feeder protection
• Transformer feeder protection
• Bus protection support
• Voltage disturbance monitoring
• System fault detection and alarming

These functions help minimize equipment damage and reduce downtime during abnormal operating conditions.

Advanced Monitoring and Metering

The relay continuously monitors feeder operating conditions and provides:

• Real-time current measurements
• Event recording
• Disturbance analysis
• Fault diagnostics
• System status indication
• Historical data logging

This information enables operators to improve maintenance planning and system reliability.

Flexible Communications

Integrated communication capabilities support modern SCADA and automation systems through:

• Modbus RTU
• DNP 3.0
• Serial communication interfaces
• Remote monitoring and control

These features simplify integration into existing power management networks.

---

Construction and Components

The 750-P5-G5-S5-HI-A20-R-E utilizes a rugged industrial design engineered for harsh electrical environments. Major internal components include:

• Motorola 68332 32-bit processing unit
• Intel 80C186 16-bit communication processor
• Protection and metering circuitry
• Analog output modules
• Communication interfaces
• Status LEDs and operator display
• Drawout relay construction for easy servicing

The dual-processor architecture separates protection and communication tasks, ensuring reliable and responsive operation.

---

Typical Applications

The relay is commonly used in:

Utility Power Distribution

• Distribution feeder protection
• Substation automation
• Distribution network monitoring

Industrial Facilities

• Manufacturing plants
• Petrochemical facilities
• Mining operations
• Steel mills
• Pulp and paper plants

Critical Infrastructure

• Data centers
• Water treatment facilities
• Transportation systems
• Power generation support systems

Its versatility makes it suitable for medium- and large-scale power distribution networks requiring dependable feeder management.

---

Installation Guidelines

For optimal performance:

1. Mount the relay securely in a standard 19-inch control panel.
2. Ensure adequate door clearance when installed adjacent to other protection devices.
3. Verify current transformer and voltage transformer wiring before energization.
4. Confirm control power voltage matches the HI power supply rating.
5. Configure protection settings according to the system coordination study.
6. Test communication links before commissioning.

---

Maintenance Recommendations

Routine maintenance should include:

• Inspection of terminal connections
• Verification of protection settings
• Event log review
• Functional testing of protection elements
• Communication diagnostics
• Firmware and configuration backup

Periodic testing helps ensure reliable protection performance throughout the relay's service life. Industry users often value the Multilin 750 series for its long-term reliability and maintainability.

---

Operational Advantages

By implementing the GE 750-P5-G5-S5-HI-A20-R-E, operators can benefit from:

• Faster fault detection and isolation
• Improved feeder reliability
• Reduced equipment damage risk
• Enhanced system visibility
• Lower maintenance costs
• Integration with modern automation systems
• Improved power distribution efficiency

These advantages contribute to safer and more reliable electrical network operation.

---

Conclusion

The GE 750-P5-G5-S5-HI-A20-R-E Feeder Protection Relay is a robust and intelligent protection solution designed for modern electrical distribution systems. Combining advanced protection algorithms, comprehensive monitoring capabilities, flexible communications, and industrial-grade construction, it remains a dependable choice for utilities, substations, and industrial power distribution applications requiring high reliability and operational efficiency.
