GE CK11CE300

I. Overview

The GE CK11CE300 is a high-voltage AC contactor manufactured by General Electric (GE), specifically designed for the industrial automation sector. It is suitable for controlling high-current circuits (such as motor starting, transformer switching, etc.). Its core function is to realize the switching control of circuits through electromagnetic operation, and it is widely used in power systems, metallurgical industry, mining machinery and other fields.

II. Parameters

• Product Model: CK11CE300
• Manufacturer: GE
• Product Type: AC Contactor
• Rated Current: 600A
• Rated Voltage: 600V AC
• Number of Poles: 3 poles
• Coil Voltage: 250/500V AC
• Auxiliary Contacts: Optional
• Mounting Method: Panel Mounting
• Operating Temperature Range: -40°C to +70°C

III. Product Features

High Reliability

• It adopts high-quality materials and advanced manufacturing processes, optimizes contact design and arc extinguishing capability, prolongs service life and reduces maintenance requirements.
• Compliant with international standards such as UL, CCC, and CE, with a built-in transient voltage suppressor to protect the coil from overvoltage damage.

Modular Design

• Supports flexible expansion: Accessories such as auxiliary contacts, delay modules, and surge suppressors can be added to meet complex control requirements.

Wide Voltage Adaptability

• The coil voltage covers 24V to 500V AC, and only 4 coils are needed to cover the full range, which is convenient for spare parts management.

Adaptability to Harsh Environments

• It has a wide operating temperature range (-40°C to +70°C), strong anti-vibration and anti-shock performance, and is suitable for harsh industrial environments.

Safety and Compatibility

• Built-in transient voltage suppressor to prevent overvoltage damage; supports a variety of industrial standards to ensure system compatibility.

IV. Structure and Composition

• Main contacts: Carry 600A current and are responsible for the on-off of the main circuit.
• Coil: Drives the electromagnetic mechanism to trigger contact action.
• Auxiliary contacts: Provide signal feedback for control loops or interlocking logic.

V. Application Fields

Industrial Automation

Power Systems

Special Industries

Other Fields

VI. Installation and Maintenance

Installation Steps

• Power-off operation: Ensure the equipment is powered off before installation.
• Check integrity: Confirm that the equipment has no physical damage.
• Wiring specifications: Connect the main circuit and control circuit according to the drawings to avoid short circuits.
• Reserved space: 100mm maintenance space needs to be reserved.

Maintenance Suggestions

Regular Inspection:

• Check whether the wiring is loose or aging.
• Clean the contact surface to prevent oxidation or poor contact.

Abnormal Handling:

• Monitor the heating of the coil to avoid faults caused by overheating.
• Replace severely worn contacts or coils in time.
