GE DS200SHVMG1AGE

I. Overview

The GE DS200SHVMG1AGE is a key component in the General Electric (GE) Mark V control system series. Its main function is to achieve precise control over the position, speed, and acceleration of mobile equipment by controlling servo motors.

II. Parameters

Electrical Parameters:

• Input Voltage: AC 115~230V / DC 12V/24V, with a frequency of 47~63Hz.
• Output Efficiency: AC efficiency ≥75%, DC efficiency ≥70%.
• Power Consumption: Maximum 4.6W.

Physical Specifications:

• Dimensions: 150mm in width × 140mm in depth × 86mm in height (with fan cooling); or 7 inches × 9.5 inches (including mounting holes).
• Weight: Approximately 2kg (module itself).

Environmental Adaptability:

• Operating Temperature: 0℃~50℃; Storage Temperature: -40℃~65℃.
• Electromagnetic Compatibility: Complies with EN55022 Class A and EN55024 standards.

III. Product Features

High Precision and Reliability:

• Supports multiple sensor inputs (analog/digital signals) and has a fast response capability (response time ≥18ms).
• Uses industrial-grade components, with an MTBF of 100,000 hours (at 25℃).

Modular Design:

• Plug-in structure for easy installation, maintenance, and replacement.
• Supports 17 jumper configurations (JP1-JP18) and 6 2-pin / 2 4-pin connectors.

Versatility:

• Integrates functions such as signal conversion, voltage attenuation, and current transformers, supporting the conversion of -500mV~500mV signals to 0~500kHz frequency output.
• Supports overcurrent, overvoltage, and short-circuit protection to ensure system safety.

IV. Structure and Composition

Hardware Configuration:

• Interfaces: 8 plug connectors and 17 jumpers (JP1-JP18) for configuring signal attenuation and drive parameters.
• Cooling: Built-in 80×80mm fan.
• Protection: Withstand voltage strength of 1800V AC (for 1 second), complying with EN60950 and CE LVD safety standards.

System Integration:

• Works in collaboration with Mark V boards to implement complex control logic and data transmission.
• Serves as a high-voltage M-frame interface board, compatible with GE exciters and drives.

V. Application Fields

Industrial Automation:

• Controls the movement of equipment such as robots, packaging machines, and machine tools.
• Used for real-time data collection and processing on production lines.

Energy Industry:

• Monitors the status of generators, boilers, and turbines in power plants to ensure safe and efficient operation.
• Used for excitation control and protection in power systems.

Special Scenarios:

• Controls large equipment (such as hoists and conveyors) in the mining, metallurgy, and petrochemical industries.
• Enables precise control of high-voltage drive systems (such as gas turbines).

VI. Installation and Maintenance

Installation Requirements:

• Usually installed in control cabinets or racks, and manufacturer guidelines must be followed to ensure compatibility.
• The power input must be stable, and signal interface connections must be secure.

Maintenance Recommendations:

• Regularly check the status of power and signal connections to avoid overloads or poor contact.
• The ambient temperature must be controlled within the range of -40℃~50℃ to avoid extreme conditions.
• Installation and maintenance should be carried out by professionals; unauthorized operations are prohibited.

————————————————————————————————————————————————————————————————————————
