GE IC660TBD025

1. General Introduction

The GE IC660TBD025 is a Genius I/O system module manufactured by General Electric (GE), belonging to the IC660 series. It is used in industrial automation systems to realize data exchange between on-site equipment and control systems, and features high reliability, fast response, and stability. This module is widely applied in the field of industrial automation, supporting digital input/output functions, and is suitable for scenarios such as industrial control, signal acquisition and control.

2. Parameters

2.1 Input/Output Configuration

• Number of input points: 16 points
• Number of output points: 8 points
• Type: Digital input/output
• Voltage level: 10~30VDC
• Current consumption: Maximum 0.5A/circuit
• Operating temperature: -20℃~60℃
• Dimension: 120×60×35 mm
• Weight: 0.2 kg

2.2 Other Parameters

• Isolation voltage: 250 V RMS
• Protection level: IP65

3. Product Features

• High reliability and stability: Advanced circuit design and industrial-grade components are adopted to ensure stable operation in harsh industrial environments.
• Modular design: Supports flexible configuration and modular installation, facilitating installation and maintenance.
• Programmability and communication capability: Supports communication interfaces (such as Genius bus), programmable functions and data exchange, and enables integration with systems like PLC and upper computer.
• Miniaturized design: Compact size saves space and facilitates integration.
• Diagnostic function: Supports fault diagnosis for easy maintenance.

4. Structure and Composition

• Modular design: Adopts a modular structure, supporting flexible configuration and expandability, which is convenient for installation and maintenance.
• Connection method: Some versions support spring clip connection or screw connection, and are compatible with multiple connection methods.
• Number of terminals: Some versions provide 25 or 32 terminals, supporting multi-channel signal input/output.

5. Application Fields

• Industrial automation: Widely used in manufacturing, electric power, oil and gas, water treatment, industrial control and other fields to connect equipment such as sensors, actuators and PLC.
• Control systems: Used for data acquisition, signal transmission and control logic implementation to support the stable operation of industrial automation systems.

6. Installation and Maintenance

• Installation: The modular design facilitates installation and maintenance, supporting rapid deployment and flexible configuration.
• Maintenance: The diagnostic function is supported, which is convenient for fault detection and maintenance, and helps extend the service life of the equipment.

————————————————————————————————————————————————————————————————————————
