GE IC670ALG310-JA – Analog Input Module for Genius I/O Systems

Product Introduction

The GE IC670ALG310-JA is a high-precision analog input module designed for the GE Genius I/O family. Engineered for stable signal acquisition in industrial automation environments, it provides accurate measurement of process variables such as temperature, flow, pressure, and level. With rugged construction and dependable conversion performance, this module ensures reliable data transmission to controllers and distributed control architectures.

---

Features & Functional Advantages

• High-accuracy analog signal conversion suitable for demanding process control

• Multi-channel input capability for efficient field wiring

• Wide compatibility with GE Genius distributed I/O systems

• Noise-resistant circuit design, ideal for environments with electrical interference

• Standardized channel configuration simplifying commissioning and integration

• Internal fault detection to ensure input reliability

• LED indicators for immediate channel and module diagnostics

• Long service lifespan, thanks to industrial-grade components and robust PCB design




---

Technical Specifications

• Model: IC670ALG310-JA

• Module Type: Analog Input Module

• Signal Type: Voltage/Current (depending on configuration)

• Number of Channels: Multi-channel analog input support

• Resolution: High-resolution A/D conversion for precision measurements

• Compatibility: GE Genius I/O and related GE Fanuc automation platforms

• Power Source: Backplane-powered module

• Input Isolation: Channel-to-system electrical isolation for safety

• Indicators: Status LEDs for supervisory diagnostics

• Operating Conditions: Industrial temperature, vibration, and EMI tolerance

• Mounting Style: Module installation in Genius I/O node assemblies




---

Structure & Internal Composition

The module is built with:

• A multi-layer industrial-grade PCB ensuring clean analog signal routing

• Dedicated A/D converters designed for stable, low-noise operation

• Input filtering circuits that reduce signal distortion from field wiring

• Isolated input channels protecting the controller from electrical surges

• Reinforced connector terminals supporting secure and corrosion-resistant wiring

• Diagnostic microelectronics providing continuous monitoring of channel health

Its robust internal architecture maintains accuracy even in electrically demanding environments.

---

Application Fields

The GE IC670ALG310-JA is suitable for a wide range of industrial processes, including:

• Chemical and petrochemical production lines

• Power generation and turbine monitoring systems

• Water treatment and distribution networks

• Food and beverage processing automation

• Oil & gas pipeline and compressor station control

• Manufacturing equipment requiring precision analog feedback

• SCADA-connected process measurement points

Any system requiring reliable analog acquisition can benefit from this module’s stable performance.

---

Installation Guidelines

1. Power down the Genius I/O node before installation.

2. Insert the IC670ALG310-JA into the designated slot and verify connector alignment.

3. Ensure field wiring follows the correct polarity, shielding, and grounding practices.

4. Tighten terminal connections to prevent signal fluctuation.

5. Restore power and observe LED indicators to confirm proper operation.

6. Calibrate or configure scaling values within the control software as required.

---

Operation & Maintenance Tips

• Conduct routine inspections for dust, wiring loosening, or connector oxidation.

• Validate analog readings periodically to detect drift or sensor degradation.

• Keep the cabinet temperature within recommended ranges for optimal accuracy.

• Use shielded twisted-pair cables for sensitive analog signals.

• Replace modules only with genuine GE components to maintain system compatibility.

---

Additional Notes

With its precise analog measurement capability, durable construction, and compatibility with GE’s distributed control architecture, the IC670ALG310-JA is a dependable solution for industries requiring accurate, real-time acquisition of critical process variables.
