GE IC698CPE010

Overview
The GE IC698CPE010 is an embedded CPU processor module designed for the GE Fanuc / GE Intelligent Platforms PAC (Programmable Automation Controller) series. It provides reliable and stable processing for industrial control applications, enabling advanced automation solutions for manufacturing, energy, and infrastructure systems. The module is engineered for high performance, deterministic control, and seamless integration into GE automation ecosystems.

---

Technical Parameters

Parameter	Details
Model	GE IC698CPE010
Type	Embedded CPU Processor Module
Series Compatibility	GE Fanuc PACSystems (RX3i / RX7i family)
CPU Performance	High-speed processing for industrial control
Memory	Supports system memory and program storage (varies by configuration)
Operating Temperature	-20°C to +60°C
Storage Temperature	-40°C to +85°C
Humidity	5% to 95% non-condensing
Communication	Supports standard PACSystems communication modules
Mounting	DIN rail or chassis installation

---

Key Features

• High-Speed Processing: Supports fast logic execution and real-time control.

• Reliable Operation: Industrial-grade design for continuous 24/7 performance.

• Flexible Expansion: Compatible with a wide range of I/O, communication, and specialty modules.

• Deterministic Control: Ensures stable timing for critical automation tasks.

• Easy Integration: Works seamlessly within GE PACSystems platforms.

---

Structure & Composition

The IC698CPE010 module is built as a compact CPU unit with essential internal components, including:

• Processor Core: Handles program execution, data processing, and system control.

• Memory Modules: Stores user programs, configuration data, and runtime information.

• Communication Interfaces: Supports connection to network modules, I/O racks, and programming terminals.

• Power Management Circuit: Ensures stable voltage regulation and protects against electrical disturbances.

• Diagnostic LEDs: Provide quick status indication for power, CPU activity, and fault conditions.

---

Typical Applications

The GE IC698CPE010 is commonly used in:

• Factory Automation Systems

• Machine Control

• Process Automation

• Packaging and Assembly Lines

• Power and Energy Management

• Water Treatment and Environmental Control




---

Installation & Maintenance

Installation Notes

• Install the CPU module into a compatible PACSystems rack or chassis.

• Ensure the power supply meets the required voltage and current ratings.

• Maintain proper ventilation around the module to prevent overheating.

• Connect communication and I/O modules according to system design and wiring standards.

Maintenance Tips

• Periodically check for dust accumulation and clean with compressed air.

• Inspect connectors and wiring for corrosion or loose contacts.

• Monitor diagnostic LEDs for abnormal indications and perform troubleshooting promptly.

• Update firmware only through official GE software tools to ensure compatibility.

---

Additional Considerations

• Compatibility Check: Ensure the IC698CPE010 is compatible with your existing PACSystems configuration and communication modules.

• Spare Parts Strategy: Keep a backup CPU module in mission-critical systems to reduce downtime.

• System Backup: Regularly back up PLC programs and configuration data to prevent loss during hardware replacement.
