GE IC698CPE040: High-Performance Controller for Complex Automation

At the heart of the RX7i PACSystem™ lies the IC698CPE040, a powerful and versatile Control Processing Engine. This central processing unit is engineered to deliver exceptional speed and reliability for demanding industrial automation applications. With a robust 40 MHz processor and substantial memory, it efficiently handles complex logic, motion control, and data acquisition tasks, making it the ideal brain for large-scale, mission-critical systems in industries ranging from manufacturing to infrastructure.

---

Core Technical Specifications

• Part Number: IC698CPE040

• Manufacturer: GE Intelligent Platforms (now part of Emerson)

• Product Series: RX7i PACSystem

• Processor Speed: 40 MHz

• Memory Configuration: 20 MB Flash, 10 MB User Memory

• I/O Capacity: Supports up to 32,768 discrete I/O points

• Backplane Communication: 2-Port PCI for high-speed internal data exchange




---

System Architecture and Key Features

This CPE module defines the capabilities of the entire RX7i rack. Its standout features include:

• High-Speed PCI Backplane: Facilitates rapid communication between the CPU and other intelligent modules in the rack, crucial for time-sensitive control.

• Extensive Memory: Ample flash and user memory support large, complex control programs and data logging without compromise.

• Scalable I/O Architecture: Capable of managing a vast array of digital, analog, and specialty I/O modules across multiple drops.

• Robust Operating System: Designed for deterministic performance, ensuring control logic executes predictably every scan cycle.

• Integrated Serial Ports: Features serial ports for configuration, programming, and communication with external devices like HMIs and bar code readers.

---

Primary Application Domains

The IC698CPE040 is built for applications where failure is not an option. Its primary uses include:

• Automated Manufacturing and Assembly Lines

• Critical Process Control in Chemical and Petrochemical Plants

• Machine Control for Large Presses, Test Stands, and Robotic Cells

• Water and Wastewater Treatment Facility Management

• Energy Management and Power Generation Systems




---

Installation and Programming Notes

Installation requires careful planning. The module must be securely inserted into the designated slot (usually slot 0 or 1) of an RX7i compatible rack. Proper grounding and power supply specifications must be strictly adhered to. Programming and configuration are accomplished using GE's Proficy® Machine Edition software. Regular maintenance involves monitoring the controller status via its LED indicators and ensuring the program memory is backed up securely after any modifications.
