GE IC698PSD300

Product Overview

The GE IC698PSD300 is a high-reliability power supply module designed for PACSystems RX3i and RX7i PLC platforms. Engineered to deliver stable DC power, it ensures uninterrupted operation of your control systems even in demanding industrial environments. This module is ideal for applications requiring robust power management and long-term operational stability.

Key Specifications

• Input Voltage: 100–240V AC, 50/60 Hz

• Output Voltage: 5V DC and 24V DC dual outputs

• Output Current: Up to 10A combined

• Power Rating: 250W

• Operating Temperature Range: 0°C to 60°C

• Storage Temperature: -40°C to 85°C

• Dimensions: 160 mm x 50 mm x 130 mm

• Weight: 600 g

• Mounting Type: DIN rail or chassis-mounted




Features

• High-efficiency power conversion for reduced energy consumption

• Dual output design supports both PLC logic and peripheral devices

• Built-in overvoltage, overload, and short-circuit protection

• LED indicators for power status and fault detection

• Compact and modular design for flexible installation

Structure & Composition

The IC698PSD300 consists of a robust metal enclosure housing the internal transformers, switching regulators, and safety circuitry. Heat-dissipating vents and an internal fan ensure consistent operation under continuous load. The module connects securely to the PLC backplane and peripheral circuits via dedicated connectors, maintaining reliable power distribution.

Applications

The IC698PSD300 is widely used across industries, including:

• Industrial automation and factory floor control systems

• Process control in chemical and pharmaceutical plants

• Material handling and packaging systems

• Water treatment facilities and energy distribution

• Any PACSystems RX3i/RX7i PLC-powered application requiring stable DC power




Installation & Maintenance

• Installation: Mount the module in the PLC chassis or on a DIN rail. Ensure proper ventilation to avoid overheating.

• Maintenance: Regularly check connections and LED status indicators. Cleaning of vents may be required in dusty environments. No periodic calibration is necessary.

• Safety Note: Disconnect power before installation or removal to avoid electric shock.

Advantages

• Provides reliable, uninterrupted power to critical automation systems

• Simplifies system design by supplying dual voltage outputs in a single module

• Compact design saves space in crowded PLC racks

• Long operational life with industrial-grade durability
