GE ILI-K001 115D2236G1

Product Overview

The GE ILI-K001 115D2236G1 is a specialized GE printed circuit board identified with the MTR POS IND function, referring to motor position indication. Available GE parts references associate ILI-K001 with part number 115D2236G1 and identify additional board references including 115D2265P2 and 117D8923G1.

As a dedicated control-system PCB, this board is intended for use within compatible GE industrial control equipment. Its role is focused on processing or supporting motor-position indication signals rather than serving as a general-purpose PLC input or output module.

Key Specifications

Item	Description
Manufacturer	GE
Board Designation	ILI-K001
Part Number	115D2236G1
Functional Description	MTR POS IND
Product Type	Industrial Control PCB
Additional Reference	115D2265P2
Associated PCB Reference	117D8923G1
Primary Function	Motor Position Indication
Application	GE Industrial Control Systems

The available parts documentation specifically lists ILI-K001 / 115D2236G1 as an MTR POS IND board. Therefore, the complete identification should be retained when sourcing a replacement.

Functional Role

Motor position information can be an important part of an industrial control loop. The ILI-K001 board is associated with circuitry used to indicate motor position within the relevant GE control architecture.

Consequently, the board should be evaluated as part of the complete control system. Sensors, feedback wiring, associated interface boards, and the main control logic can all affect the final position indication.

Because this is a specialized board, replacing it with a visually similar PCB is not recommended. The exact board designation and part number should be compared before installation.

PCB Construction

The 115D2236G1 is an electronic printed circuit board assembly containing the circuitry and interfaces required for its designated motor-position indication function. Parts listings identify it specifically as an MTR POS IND PCB, while some inventories also describe it as a blank printed circuit board listing.

For maintenance teams, the ILI-K001 designation is particularly useful because it provides an additional way to identify the board in parts lists and equipment documentation.

Industrial Applications

The GE ILI-K001 115D2236G1 can be used in compatible GE industrial control equipment where motor position monitoring or indication is required. Potential environments include power-generation equipment, industrial machinery, turbine-related control systems, and legacy automation installations.

Furthermore, maintaining a spare board can help reduce downtime when an existing PCB experiences component failure, connection problems, or other electronic faults.

Installation and Maintenance

Before replacement, technicians should verify the board number, ILI-K001 designation, connector arrangement, revision information, and associated equipment. The existing board should be documented before removal so that wiring and installation orientation can be reproduced accurately.

During maintenance, inspect connectors for oxidation, loose contacts, contamination, and mechanical damage. Also check the associated motor-position feedback circuits before concluding that the PCB itself is defective.

Our company supplies the GE ILI-K001 115D2236G1 for industrial control maintenance and replacement applications. Product condition and exact revision can be confirmed according to project requirements before ordering.

————————————————————————————————————————————————————————————————————————
