GE IS215UCVEM01A – VMEbus Controller Module (Mark VI Control System)

Description

The GE IS215UCVEH2AF is an enhanced UCVE-series controller, part of the Mark VIe control platform. It integrates high-speed processing, built-in network switching, and secure firmware services for mission-critical turbine and plant automation.
It is often deployed in triple-modular-redundant (TMR) or dual-redundant architectures to ensure maximum uptime.

---

Technical Specifications

• CPU Type: High-performance GE embedded processor

• Memory: ECC-protected RAM with extended temperature support

• Non-volatile storage: Flash + removable memory card

• Native network ports: 3× Ethernet (deterministic control + HMI/SCADA)

• Backplane: Direct interface to Mark VIe I/O Network

• Operating temperature: –30 °C to +70 °C (industrial grade)

• Real-time clock: Battery-backed time synchronization

• OS Compatibility: GE secure real-time OS, supports cybersecurity patches

• Power source: Supplied from backplane, no external wiring




---

Internal Functional Blocks

1. Main CPU core – Executes turbine sequencing + process logic

2. System Monitor ASIC – Handles watchdog, health, and reset signals

3. Redundant Ethernet switching – Supports EGD & Profinet communication

4. Flash firmware section – Secure boot + firmware integrity checks

5. Diagnostics interface – Accessible via USB or serial

6. Thermal & voltage monitoring – Hardware-level protection

---

Application Domains

• Mark VIe control for Frame 6, Frame 7, Frame 9 gas turbines

• Steam turbine protection modules

• Petrochemical and refinery rotating equipment control

• Integrated DCS + Turbine Digital Valve systems

• Subsea or offshore turbine package controls

• Long-life industrial retrofits replacing older IS215UCVEM units




---

Installation & Maintenance

• Insert directly into Mk VIe control rack backplane

• Firmware loaded via ToolboxST or field upgrade USB kit

• Can operate in simplex, dual, or TMR redundancy

• Event logs and fault codes retrievable without shutdown

• No battery replacement required under normal lifecycle

---

Additional Notes

• “H2AF” suffix indicates enhanced processing + advanced firmware security

• Backward compatible with older UCVE modules through configuration migration

• Included in GE’s long-term service & parts life-extension program
