GE IS220PDOAH1BC

Product Overview

The GE IS220PDOAH1BC Discrete Output I/O Pack is an intelligent field interface module developed for the GE Mark VIe and Mark VIeS control systems. As part of the distributed I/O architecture, it serves as the communication bridge between the controller's IONet Ethernet network and field output terminal boards, converting digital control commands into reliable discrete output signals for industrial equipment.

Designed for demanding turbine control and process automation applications, the IS220PDOAH1BC supports high-speed Ethernet communication, integrated diagnostics, and flexible system configurations including simplex and Triple Modular Redundancy (TMR). Its compact design and industrial-grade construction make it suitable for continuous operation in harsh environments.

---

Features and Performance

High-Speed Distributed I/O Communication

The IS220PDOAH1BC communicates through dual 10/100 Mbps Ethernet interfaces, enabling fast and reliable data exchange with the Mark VIe controller. The redundant network design improves communication availability and minimizes downtime.

Reliable Discrete Output Control

The module is designed to control up to 12 relay output channels, making it suitable for driving field devices such as contactors, relays, solenoid valves, alarms, and auxiliary control equipment. It also supports feedback monitoring from compatible terminal boards to improve operational reliability.

Advanced Diagnostic Functions

Integrated diagnostics continuously monitor power supply status, Ethernet communication, processor health, and output operation. Front-panel LED indicators provide clear visual information for commissioning and maintenance, allowing engineers to quickly identify system conditions.

Flexible System Integration

The IS220PDOAH1BC can be deployed in simplex, dual, or TMR system architectures and is compatible with several GE relay terminal boards, providing flexibility for different industrial control requirements.

---

Technical Specifications

• Manufacturer: GE (General Electric)
• Model: IS220PDOAH1BC
• Product Type: Discrete Output I/O Pack (PDOA)
• Series: Mark VIe / Mark VIeS
• Output Capacity: Up to 12 relay control channels
• Communication Interface: Dual 10/100 Mbps RJ-45 Ethernet ports
• Power Supply: Nominal 28 VDC
• Processor: Industrial embedded processor
• Memory: 128 MB Flash memory
• Output Connector: DC-37 connector
• Configuration Support: Simplex, Dual, and TMR
• Diagnostic LEDs: Power, Attention, Link, TX/RX
• Operating Temperature: Approximately -30°C to +65°C (depending on system configuration)
• Compatible Terminal Boards: TRLY and SRLY series relay terminal boards

---

Construction and Typical Applications

The IS220PDOAH1BC integrates an embedded processor, Ethernet communication circuitry, output driver electronics, memory, diagnostic components, and a dedicated acquisition board into a compact I/O pack. The module connects directly to compatible terminal boards through a DC-37 connector while communicating with the controller over the IONet network. This architecture reduces wiring complexity and improves system scalability.

Typical applications include:

• Gas turbine control systems
• Steam turbine automation
• Combined-cycle power plants
• Industrial power generation
• Oil and gas facilities
• Petrochemical plants
• Compressor and auxiliary equipment control
• Process automation systems

---

Installation and Maintenance

The GE IS220PDOAH1BC is designed for straightforward installation on compatible Mark VIe terminal boards. During installation, the module should be securely mounted, connected to one or two Ethernet networks as required by the control architecture, and powered with a 28 VDC supply. Built-in soft-start technology helps reduce inrush current during power-up.

To maintain reliable operation, engineers should periodically inspect Ethernet connections, verify LED status indicators, check terminal board connections, and monitor diagnostic information through the GE ControlST engineering software. Routine preventive maintenance and the use of genuine replacement modules help maximize system availability and extend service life.

————————————————————————————————————————————————————————————————————————
