GE IS230TNRLH1B

The GE IS230TNRLH1B is a relay output DIN rail module manufactured by General Electric (GE), belonging to the Mark VIe series. It is specifically designed for industrial automation and safety-critical applications. As a core component of the Safety Instrumented System (SIS), this module is widely used in industries such as oil, gas, petrochemicals, and electric power to control process flows in high-risk environments. Its core function is to control high-power equipment through digital outputs while providing electrical isolation to ensure system safety.

Parameters

Model and Manufacturer

• Model: IS230TNRLH1B
• Manufacturer: General Electric (GE)
• Series: Mark VIe

Electrical Parameters

• Output Type: 16-channel digital relay output
• Output Voltage Levels: 24V DC, 120V AC, 240V AC (configurable based on requirements)
• Isolation Method: Optically isolated outputs
• Safety Certifications: Compliant with IEC 61508 standard, with SIL 2 and SIL 3 capabilities

Physical and Environmental Parameters

• Dimensions: 17.8 cm (width) × 33.02 cm (depth)
• Operating Temperature: -40°C to +70°C
• Communication Interface: Tricon Communication Module (TCM)
• Country of Manufacture: United States (USA)

Product Features

Core Functions

• Serves as an interface between low-voltage control circuits and high-power equipment, enabling signal switching, load control, and electrical isolation.
• Supports multiple output voltage configurations to meet the needs of different industrial scenarios.

Safety and Reliability

• Prevents damage to the control system from voltage spikes and electrical faults through optical isolation technology.
• Compliant with IEC 61508 SIL 2/SIL 3 standards, suitable for high-risk industrial environments.

Design and Compatibility

• Adopts DIN rail mounting, saving space and facilitating integration.
• Seamlessly collaborates with Mark VIe controllers (based on the QNX Neutrino operating system), supporting real-time, multi-tasking processing and efficient communication.

Structure and Composition

Internal Components

• Fuses and Transformers: Built-in 7 fuses and 4 transformers (3 in parallel, 1 independent).
• Terminals and Connectors: 6 terminal blocks, over 25 test points, 45 plugs/connectors (including conductive connectors, vertical pin connectors, etc.).
• Electronic Components: Coil inductors, resistors, relays, diodes, capacitors, integrated circuits, etc.
• Voltage Regulation: Three-sided voltage regulation circuits, covering over 100 voltage regulators.

Installation Method

• Fixed installation via DIN rails (width 6.2 mm to 22.5 mm).

Application Fields

Industrial Automation

• Used in gas/steam turbine control systems (Mark VIe system) to achieve precise control and diagnosis.
• Supports Windows-based HMI interfaces, facilitating programming and maintenance.

Safety-Critical Industries

• Oil, gas, and petrochemical industries: Control critical process parameters (such as valves, motors).
• Electric power industry: Used in redundant control systems of power plants.

Other Fields

• Voltage regulation, digital solutions, industrial process control, etc.

Installation and Maintenance

Installation Steps

• Rail Installation: Insert the module into the DIN rail and ensure it is firmly fixed.
• Wiring and Configuration: Connect terminal blocks and jumper switches as required, and set the output voltage level.

Maintenance and Support

• Daily Inspection: Regularly test terminal connections, fuse status, and output loads.
• Troubleshooting: Locate problems through test points and diagnostic tools, supporting remote monitoring.
• Technical Support: Provide a 1-year warranty and after-sales support, covering a global scope.

Precautions

• The working environment must meet the temperature range (-40°C to 70°C) and anti-vibration/shock requirements.
• Follow the real-time and reliability design specifications of the QNX Neutrino operating system.

————————————————————————————————————————————————————————————————————————
