GE SLN042-IC086SLN042-A

Product Overview

The GE SLN042 (IC086SLN042-A) is a high-reliability digital output module designed for the GE Series 90-30 and PACSystems automation platforms. This module allows control systems to drive external devices such as solenoids, relays, and indicators, providing precise and fast switching of discrete signals. Its robust design ensures consistent performance in industrial environments.

---

Key Features

• High-Speed Switching: Capable of driving multiple discrete loads with minimal latency

• Flexible Output Configuration: Supports sourcing and sinking configurations for various loads

• Diagnostic Monitoring: LED indicators for output status and fault detection

• Industrial-Grade Reliability: Resistant to vibration, temperature variations, and electrical interference

• Seamless Integration: Rack-mounted and compatible with Series 90-30 / PACSystems backplanes

---

Technical Specifications

Parameter	Specification
Model Number	SLN042 / IC086SLN042-A
Module Type	Digital Output
Compatible Systems	Series 90-30, PACSystems
Output Channels	4 discrete outputs
Output Type	Sourcing or sinking (system dependent)
Load Voltage	Typically 24 VDC (check system configuration)
Switching Current	Up to 0.5–1 A per channel (typical)
Isolation	Channel-to-channel and channel-to-backplane
Mounting	Rack-mounted
Operating Temperature	0°C – 60°C

---

Structure & Composition

The SLN042 module includes:

• Output driver circuits for each channel

• LED indicators for real-time channel status

• Protection resistors and clamping diodes for inductive loads

• Backplane connector for power and communication

The compact design allows installation in standard GE automation racks with front-access wiring terminals. Its internal protection ensures safe operation even when switching inductive or reactive loads.

---

Application Areas

The GE SLN042 is used in various industrial control scenarios, such as:

• Actuating solenoid valves and relays in process automation

• Controlling indicator lights or alarm systems

• Interface with motor starters or small DC loads

• Automated manufacturing and assembly lines

• Water treatment and pumping systems

---

Installation & Maintenance

• Insert the module into the designated rack slot and connect output devices to the front terminals

• Verify output voltage and polarity before energizing the module

• Check LED indicators regularly for operational faults

• Clean dust accumulation and inspect wiring connections periodically

---

Summary

The GE SLN042 / IC086SLN042-A is a reliable, fast, and flexible digital output module for GE Series 90-30 and PACSystems platforms. Its robust design and integrated diagnostics make it ideal for controlling discrete industrial loads in demanding automation environments.
