GE VME-PMC-CADDY PMC

The GE VME-PMC-CADDY is a specialized PMC carrier adapter designed to support the integration of PMC (PCI Mezzanine Card) modules into VMEbus-based systems. This accessory module provides a mechanical and electrical interface that allows users to expand system functionality while maintaining compatibility with existing VME architectures.

---

Functional Role in VME Systems

Rather than acting as a processing unit, the VME-PMC-CADDY serves as an expansion and mounting solution. It enables flexible system configuration by allowing PMC modules—such as communication, data acquisition, or I/O cards—to be securely installed and connected within VME platforms.

Common usage scenarios include:

• VME systems requiring additional I/O channels

• Embedded control platforms with modular expansion needs

• Defense and aerospace systems using PMC-based peripherals

• Industrial automation systems with customized interface requirements




---

Mechanical Structure and Components

The module features a rugged mechanical frame designed to securely hold PMC cards during operation. Precision-aligned connectors ensure stable electrical contact, while the structural design supports resistance to vibration and mechanical stress often found in industrial and mission-critical environments.

Key structural elements include:

• PMC card mounting frame

• High-quality electrical connectors

• VME-compatible mechanical interface

• Reinforced structure for long-term durability

---

Technical Characteristics

The main technical attributes are summarized below in a descriptive format:

• Product Type: PMC Carrier / Adapter Module

• Model: VME-PMC-CADDY

• Manufacturer: GE

• Bus Compatibility: VMEbus systems

• Supported Modules: Standard PMC cards

• Function: Mechanical and electrical PMC integration

• Installation Method: Mounted within VME chassis

---

Key Advantages

• Enables flexible expansion of VME systems

• Supports a wide range of standard PMC modules

• Rugged design suitable for harsh environments

• Simplifies system upgrades without major redesign

• Ensures stable signal and power connections




---

Installation Considerations

Installation involves securing the PMC module into the caddy and then mounting the assembly into the VME system according to standard procedures. Care should be taken to ensure correct alignment and proper fastening to avoid connector stress.

Adequate airflow within the chassis should be maintained, especially when using high-power PMC cards.

---

Maintenance and Service

The GE VME-PMC-CADDY requires minimal maintenance. Periodic checks should focus on:

• Mechanical fastening integrity

• Connector cleanliness

• Signs of wear from repeated module replacement

Under normal conditions, it provides reliable service over extended operational periods.

---

Additional Information

The GE VME-PMC-CADDY is an ideal solution for engineers seeking to enhance the flexibility and scalability of VME-based systems. By supporting modular expansion, it helps extend the lifecycle of legacy platforms while accommodating evolving application requirements.

————————————————————————————————————————————————————————————————————————
