GE IC200PWR101D – Power Supply Module for VersaMax PLC Systems

The GE IC200PWR101D is a compact power supply module designed for the GE VersaMax PLC series. It provides stable and regulated power to the CPU, I/O modules, and field devices within a modular PLC rack. Engineered for industrial environments, this unit ensures continuous operation, electrical protection, and long-term reliability in automation control systems.

---

Main Specifications

• Input Voltage Range: 120/240 VAC

• Output Voltage: 5 VDC regulated

• Output Current: Up to 3 A (supports up to 8 I/O modules depending on load)

• Inrush Protection: Built-in current limiting

• Status Indication: Front-panel LED for power and fault state

• Operating Temperature: 0°C to +60°C

• Storage Temperature: -40°C to +85°C

• Cooling: Passive air convection, no fan required

• Module Mounting: Backplane slot for VersaMax power base

• Certifications: UL, CE, cUL, and industrial EMC compliance




---

Internal Structure & Design

The IC200PWR101D consists of the following functional sections:

1. AC Input Filtering Stage – Protects against line noise and voltage spikes

2. Switching Regulation Circuit – Generates stable 5V output for module logic power

3. Thermal & Overload Protection System – Automatically shuts down on critical overload

4. Backplane Power Interface – Delivers distribution power to attached modules

5. LED Diagnostic Indicators – Provides visual feedback for power status and module health

---

Key Features & Benefits

• Universal AC input makes installation flexible worldwide

• High output stability ensures reliable PLC logic execution

• Designed for long MTBF (Mean Time Between Failures) in harsh industrial settings

• Supports power redundancy when paired with additional supplies

• Compact size ideal for space-limited control panels

• Fully integrated with GE VersaMax modular architecture




---

Typical Industrial Applications

• Machine automation and factory production lines

• Water treatment and municipal utility control cabinets

• Packaging, conveyor, and bottling systems

• HVAC, building automation, and facility monitoring

• Material handling and assembly cell control

• GE VersaMax PLC expansion and retrofit projects

---

Installation & Maintenance

Installation Steps

1. Ensure main power is OFF before inserting the module.

2. Mount IC200PWR101D into the first slot of the VersaMax power base.

3. Wire AC input to the terminal block according to local standards.

4. Tighten terminal screws to recommended torque to prevent vibration loosening.

5. Power ON and observe the LED indicator to confirm normal operation.




Maintenance Tips

• Periodically check terminal block wires for loosening due to thermal cycling.

• Replace only with GE-certified modules to maintain electrical compatibility.

• Store spare units in dry, anti-static packaging with stable temperature.

• Avoid exposure to corrosive gases or conductive dust inside the control cabinet.

---

Additional Notes

• One power supply module is required per VersaMax rack; additional loads may require auxiliary power.

• The revision letter “D” indicates an updated hardware version with improved internal components.

• Often used as a drop-in replacement in legacy VersaMax installations and OEM equipment.
