Product Description

GE 369-HI-R-M-0-0-0-E

Overview

The GE 369-HI-R-M-0-0-0-E is a core product in General Electric (GE)'s Multilin 369 series of motor management relays. Designed specifically for industrial applications, it aims to ensure the stability and safety of motors and their associated equipment in complex operating environments through highly reliable protection and control. This product is widely used in manufacturing, power, HVAC systems, pump stations, wind power generation, and other fields. It supports motor overload protection, soft start, fault alarm, and other functions, making it suitable for industrial automation, building control, and energy management scenarios.

Parameters

  • Input Voltage: 50-300 VDC or 60-265 VAC (some documents mention 60-264 VAC, which may be due to version differences).
  • Output Voltage: 0~250 VAC (not clearly specified in some materials, but default is AC output).
  • Output Current: 0~10A (some data mention a rated current of 20A, so attention should be paid to model differences).
  • Frequency: 50-60 Hz (not clearly specified in some materials, but default is industrial standard frequency).
  • Protection Rating: IP20 (some materials mention IP65, which may be an upgraded version).
  • Operating Temperature Range: -40°C to +70°C (some materials mention -20°C to 55°C, please refer to the latest version).
  • Storage Temperature Range: -40°C to +85°C (some materials mention -40°C to 85°C, which is consistent).
  • Humidity Range: 5% to 95% RH (no condensation).
  • Dimensions and Weight:
    • Dimensions: Approximately 200 mm x 156 mm x 101 mm (some materials mention 11.5 inches x 5.5 inches x 8.5 inches, attention should be paid to unit conversion).
    • Weight: Approximately 4.5 kg (some materials mention 1.5 kg or 2 kg, please refer to the actual model).

369-HI-R-M-0-0-0-E

Product Features

High Reliability and Versatility

It adopts modular design and redundancy technology, supporting multiple protection functions (such as overcurrent, undervoltage, phase loss, ground fault, etc.). It integrates microprocessor technology to provide precise measurement and control functions, and supports RS232/RS485 communication.
It supports advanced functions such as pre-trip alarm, over-torque correction, and RPTD temperature protection.
It supports DIN rail or wall-mounted installation, with simple wiring and low maintenance costs.
With high protection ratings (IP20/IP65) and a wide temperature and humidity range, it is suitable for harsh conditions in industrial sites.

Structure and Composition

It supports wall-mounted or DIN rail installation, facilitating integration into control cabinets or operation panels.
It can be connected via cable wiring or terminals, with strong compatibility.
It has 12 built-in RTD input ports and supports extended functions (such as metering module M).
It is equipped with an enhanced display screen, providing an intuitive user interface and fault diagnosis functions.

Application Fields

Used for production line motor control, conveyor systems, automation equipment, etc.
Protects key equipment such as air conditioning compressors and fans.
Applied in scenarios such as power plants, solar arrays, and power grid protection.
Used for motor control in railways, electric vehicles, and other fields.

Medical and Construction

Supports precise control of medical equipment and energy-saving management of building HVAC systems.
Select DIN rail or wall-mounted installation according to requirements, ensuring firm fixation. Connect the power and load terminals according to the wiring diagram, paying attention to polarity matching.
Regularly check whether the wiring terminals are loose, and clean the shell surface to prevent dust accumulation. Use the built-in diagnostic function to monitor the fault status and adjust parameters in a timely manner.
Follow safety specifications and avoid operation in humid or high-temperature environments. It is recommended to update the firmware regularly to obtain the latest function optimizations.

————————————————————————————————————————————————————————————————————————
