GE IC660BBD110

1. General Description

The GE IC660BBD110 is a 16-point discrete input module manufactured by GE (General Electric). It belongs to the PACSystems RX3i series and is specifically designed for signal acquisition and status monitoring in industrial automation. This module collects the status of external devices (such as switches and sensors) via digital signals and converts them into signals recognizable by a Programmable Logic Controller (PLC), making it widely applicable in industrial control and automation systems.

2. Technical Parameters

• Input Channels: Equipped with 16 discrete input channels, supporting digital signal acquisition.
• Input Type: Digital input, compatible with 2-wire or 3-wire proximity switch inputs. The rated voltage range is 93-132VAC (with a rated value of 115VAC).
• Input Characteristics: Features advanced functions including programmable threshold (25%-85%), input filtering (10-100ms), short-circuit/open-circuit detection, and software configuration.
• Physical Characteristics: Measures 8.83”×3.34”×3.91” (approximately 22.44cm × 8.48cm × 9.93cm) and weighs about 1.8kg. It supports front-and-back mounting as well as DIN rail mounting.
• Operating Environment: Operates within a temperature range of 0-60°C, with a storage temperature range of -40-100°C. The humidity tolerance is 5-95% (non-condensing).
• Certifications and Protection: Has an IP20 protection rating and complies with certifications such as CE and UL.

3. Product Features

• Functions: Enables signal acquisition, status monitoring, fault diagnosis (e.g., short-circuit/open-circuit detection), software configuration, and programmable threshold setting.
• Technical Advantages: Built on the Microchip PIC32MX795F512H microcontroller, it adheres to the IEC 61131-2 standard, ensuring suitability for high-reliability industrial applications.
• Installation and Maintenance: Boasts a compact design, supporting flexible installation (either DIN rail mounting or direct mounting). It is equipped with LED indicators (for Unit OK, I/O enable, and individual input status) for easy status checking.

4. Structure and Composition

• Core Components: A microcontroller-based digital input module that includes input channels, isolation circuits, communication interfaces (such as the Genius bus), and diagnostic function modules.
• Interfaces: Supports Genius bus communication, allowing direct connection to controllers or communication adapters. It also supports the Daisy-chain network topology.
• Physical Structure: Features a compact design, incorporating terminal blocks, LED indicators, and accessible internal interfaces.

5. Application Fields

• Industrial Automation: Used for signal acquisition, status monitoring (e.g., monitoring the status of switches and sensors), fault diagnosis, and process control in industrial control systems.
• Application Scenarios: Suitable for scenarios requiring high reliability and real-time performance, such as power systems, industrial automation equipment, robot control, and process control.

6. Installation and Maintenance

• Installation: Supports DIN rail mounting or direct mounting. It is essential to ensure proper grounding and good ventilation, with a minimum installation spacing of 2 inches.
• Maintenance: Regularly inspect connections and clean the module to avoid exposure to humid environments. Additionally, periodically check the short-circuit/open-circuit fault detection function to ensure its normal operation.

————————————————————————————————————————————————————————————————————————
