GE Fanuc IC695CPL410

Product Overview

The GE Fanuc IC695CPL410 is a PACSystems RX3i rackless CPU and standalone edge controller designed for advanced industrial automation applications. Unlike conventional RX3i CPUs that are installed in a backplane, the CPL410 is a standalone controller that can be mounted directly on a DIN rail or inside a control cabinet.

The controller combines deterministic PLC control with an integrated Linux environment, making it suitable not only for traditional machine and process control but also for data processing, edge analytics, web visualization, and industrial connectivity.

Core Specifications

Parameter	Specification
Manufacturer	GE Fanuc / Emerson
Model	IC695CPL410
Product Family	PACSystems RX3i
Product Type	Rackless CPU / Edge Controller
Processor	1.2 GHz AMD G-Series Quad-Core
User Memory	64 MB configurable program and data memory
Operating System	VxWorks / integrated Linux environment
Program Blocks	Up to 768
Maximum Block Size	128 KB
Input Voltage	18–30 VDC
Maximum Input Power	20 W
Display	OLED
Mounting	DIN rail or panel
USB	2 × USB 3.0
Ethernet	Multiple Ethernet interfaces
Security	Secure Boot and TPM

Emerson's current product information identifies the IC695CPL410 as a 1.2 GHz AMD G-Series quad-core controller with 18–30 VDC input power and a maximum consumption of 20 W.

Control and Edge Computing

One of the main strengths of the IC695CPL410 is the combination of PLC control and Linux-based computing. The embedded RX3i PLC supports programming languages including Ladder Diagram, Structured Text, Function Block Diagram, and C, while the Linux environment can be used for additional data-processing and connectivity functions.

This architecture allows a single controller to handle conventional automation tasks while also supporting higher-level applications such as:

• Industrial data processing
• Edge analytics
• Cloud connectivity
• Web-based visualization
• Local data storage
• Custom software applications
• Industrial protocol integration

The controller provides 64 MB of configurable program and data memory and supports up to 768 program blocks, with a maximum block size of 128 KB.

Communication and Network Features

The IC695CPL410 provides extensive communication capability for modern industrial automation systems. Available configurations include multiple Ethernet interfaces, USB connectivity, and a serial communication interface. The embedded controller also supports industrial protocols such as SRTP, Modbus TCP, Ethernet Global Data, OPC UA, and DNP3.

For PROFINET applications, the integrated PROFINET I/O Controller can support up to 64 I/O devices in a simplex configuration or 32 devices in a Hot Standby Redundancy configuration, depending on the system arrangement and configuration.

The controller can therefore act as both an automation processor and a communication gateway between field-level equipment and higher-level industrial networks.

Applications and Installation

The rackless design makes the GE Fanuc IC695CPL410 particularly useful where cabinet space, distributed control, or standalone automation architecture is important. Typical applications include:

• Factory automation
• Machine control
• Process automation
• Packaging equipment
• Material handling
• Distributed control systems
• Industrial data acquisition
• Edge computing
• Energy and utility automation
• PROFINET-based control systems

The CPL410 can be mounted using a DIN-rail adapter or a panel-mount adapter, eliminating the requirement for a traditional RX3i CPU backplane slot.

Maintenance and Replacement Considerations

Before installing or replacing an IC695CPL410, verify the complete catalog number, firmware version, application program, network configuration, power supply, and connected I/O devices. The controller should be powered from an appropriate 18–30 VDC supply, and the mounting arrangement should provide adequate ventilation and mechanical support.

The front OLED display provides useful status and configuration information, while the controller's diagnostic functions can assist technicians in identifying communication, processor, and system conditions.

For replacement projects, it is also important to distinguish the standard IC695CPL410 from related variants such as IC695CPL410CA, which is a conformal-coated version.

For industrial automation spare-parts management, the GE Fanuc IC695CPL410 is a valuable RX3i controller for applications requiring compact installation, high-performance PLC processing, and integrated edge-computing capabilities.

————————————————————————————————————————————————————————————————————————
